Den här produkten finns inte längre i vårt sortiment, men kontakta oss gärna på 031-710 20 00 eller kundservice@komplett.se så hjälper vi dig hitta ett bra alternativ.
SAPPHIRE NITRO+ & PULSE AMD Radeon™ RX 7700 Series are designed with digital power which provides accurate power control and excellent power efficiency
Ultra High Performance Conductive Polymer Aluminum Capacitor
The Ultra High Performance Conductive Polymer Aluminum Capacitor has a small PCB foot print but high volumetric capacitance that makes 14-phase power possible on the RX 7700 series graphics card. The capacitor offers stable capacitance at a high frequency and temperature with very low signal noise, ensuring the stability and reliability of the product.
High TG Copper PCB
The GPU is mounted on to the high-density 14 layer 2oz Copper and high TG PCB to match the rapid speed, high current and increased power requirement of the GPU and memory to guarantee high stability of the PCB during operation.
Angular Velocity Fan Blade
The Angular Velocity Fan Blade provides a double layer of downward air pressure which alongside the air pressure on the outer ring of the Axial fan, results in up to 44% more downward air pressure and up to 19% more airflow for a quieter and cooler operation when compared to the previous generations.
Optimized Composite Heatpipe
The composite heatpipes are fine-tuned for each individual cooling design with optimal heat flow, efficiently and evenly spreading out the heat to the entire cooling module.
Fuse Protection
In order to protect your card, the SAPPHIRE cards have fuse protection built into the circuit of the external PCI-E power connector to keep the components safe.
Two-Ball Bearing
These feature Dual Ball bearing fans, which have an approximately 85% longer lifespan than sleeve bearings in our tests. The improvements to the fan blades means the solution is up to 10% quieter than the previous generation.
Allmänt
Produktlinje
Sapphire Pulse Radeon
Modell
RX 7600
Producentens garanti (månader)
36
EAN
4895106293618
Videoutgång
Typ
Grafikkort
API-stöd
DirectX 12 Ultimate
VR-förberedd
Ja
Grafikprocessortillverkare
AMD
Maximal extern upplösning
7680 x 4320
Typ av gränssnitt
PCI Express 4.0 x8
Antal strömprocessorer
2048
Grafikprocessor
AMD Radeon RX 7600
Maximalt antal skärmar
4
Snabb klockhastighet
2755 MHz
Utgångsportar (kompaktlista)
3 x DisplayPort, HDMI
Egenskaper för videoadapter
Kompositvärmerör, 2-slot Fan Cooler, Precision Fan Control, Sapphire Dual-X Cooling Technology, Säkringsskydd, FreeSync Technology, AMD VR Ready Premium, AMD Radeon Boost Technology, AMD smart åtkomstminnesteknik, RDNA 3 gamingarkitektur, TriXX Boost, Radeon bildskärpning, AMD Radeon Anti Lag Technology, Intelligent Fan Control (IFC), TriXX Supported, Dual Fan Design, 32 strålföljningsacceleratorer, UEFI BIOS, Optimerade speldrivrutiner, Bakre aluminiumplåt, AMD FidelityFX Super Resolution 2 (FSR), Videostreaming upp till 8K, AMD Infinity Cache, 32 dataenheter, Fläktar med dubbla kullager, AMD Radeon Super Resolution (RSR)
Videosignal som stöds
DisplayPort, HDMI
Videominne
Bussbredd
128-bit
Installerad storlek
8 GB
Minnehastighet
18 Gbps
Teknik
GDDR6 SDRAM
Nätdel
Energiförbrukning vid drift
185 Watt
Systemkrav
Min RAM-storlek
8 GB
Extra krav
8-stifts PCI Express-strömkontakt
Erforderligt nätaggregat
550 W
Operativsystem erfordras
Windows 10 (64-bit), Windows 11, Linux (64-bitars)
Diverse
Standarder som följs
DisplayPort 1.4
Färgkategori
Röd, Svart
Mått och vikt
Bredd
4.407 cm
Djup
24 cm
Höjd
10.71 cm
Gränssnittsdetaljer
Gränssnittsdetaljer
HDMI, 3 x DisplayPort (Display Stream Compression (DSC))
